Prix FOB
Obtenir le dernier prix10 ~ 90 USD / Piece ( Negotiable )
|1 Piece Minimum Order
Pays:
China
N ° de modèle:
FSCT36
Prix FOB:
10 ~ 90 USD / Piece ( Negotiable ) Obtenir le dernier prix
Localité:
China
Prix de commande minimale:
10 per Piece
Commande minimale:
1 Piece
Packaging Detail:
Cartons
Heure de livraison:
3-7 days
Capacité de Fournir:
20000 Piece per Week
Payment Type:
T/T, L/C, D/A, D/P
Groupe de produits :
Personne àcontacter Mr. Jay
No.68, Tian'an Cyberpark, No.55 Changshan Avenue, Jiangyin, Wuxi, Jiangsu
IP67 Fsct-36 150A/5A Outdoor Waterproof Split Core CT Current Transformer FSCT-36 Outdoor Waterproof current transformer is built with silicone steel core and is potted for outdoor use.  In addition, it is designed for easy installation on ground potential conductors. Â
| Model | WSCT-60 |
| Model | FSCT-36 |
| Window size | 36mm |
| Rated primary current | 100-800 Arms |
| Rated output | 5A/1A |
| IP rating | IP 67 |
| Burden | 1.5VA -5VA |
| Max current | 800 Arms |
| Turns | 100-3000T |
| Accuracy class | 0.5, 1.0 |
| Equipment maximum voltage | 0.66/0.72KV |
| Wire lead | 2*2.5mm2 sheathed wire |
| Insulation strength | 3KVac/min |
| Insulation impedance | DC500V/100MΩ |
| Rated frequency | 50-400HZ |
| Working temperature | -25ºC~70ºC |
| Storage temperature | -30ºC~80ºC |
| Pays: | China |
| N ° de modèle: | FSCT36 |
| Prix FOB: | 10 ~ 90 / Piece ( Negotiable ) Obtenir le dernier prix |
| Localité: | China |
| Prix de commande minimale: | 10 per Piece |
| Commande minimale: | 1 Piece |
| Packaging Detail: | Cartons |
| Heure de livraison: | 3-7 days |
| Capacité de Fournir: | 20000 Piece per Week |
| Payment Type: | T/T, L/C, D/A, D/P |
| Groupe de produits : | split core CT/current transformer |
