Prix FOB
Obtenir le dernier prix10 ~ 90 USD / Piece ( Negotiable )
|1 Piece Minimum Order
Pays:
China
N ° de modèle:
RSCT-
Prix FOB:
10 ~ 90 USD / Piece ( Negotiable ) Obtenir le dernier prix
Localité:
China
Prix de commande minimale:
10 per Piece
Commande minimale:
1 Piece
Packaging Detail:
cartons
Heure de livraison:
7-15 days
Capacité de Fournir:
500 Piece per Day
Payment Type:
L/C, T/T
Groupe de produits :
Personne àcontacter Mr. Jay
No.68, Tian'an Cyberpark, No.55 Changshan Avenue, Jiangyin, Wuxi, Jiangsu
Jiangyin Spark FCT is flexible, like rope ,it is designed to use where solid or split core current transformers cannot fit Advantage including high accuracy, wide measurement and frequency range and very light weight.The probes comprise a flexible air-cored sensor which can be opened, allowing them to be installed around a primary conductor without interrupting the circuit. The flexible and lightweight measuring head allows quick and easy installation in hard to reach areas and with large conductors.
 Specifications Of 0.333V Flexible Rogowski Coils Current Transformers| Rated current (rms) | 10A-100KA |
| Output | mV (without integrator) |
| 0.333V,0-5V AC(with integrator) | |
| Power supply | 9V,15V,24V DC |
| Coil length | 20cm-200cm |
| Tube | UL material |
| Wire lead | Shielded cable |
| Isolation voltage | 3000V |
| Operating temperature | -25ºC-+70ºC |
| Frequency | 50Hz-60Hz |
| Accuracy | ±1% |
| Pays: | China |
| N ° de modèle: | RSCT- |
| Prix FOB: | 10 ~ 90 / Piece ( Negotiable ) Obtenir le dernier prix |
| Localité: | China |
| Prix de commande minimale: | 10 per Piece |
| Commande minimale: | 1 Piece |
| Packaging Detail: | cartons |
| Heure de livraison: | 7-15 days |
| Capacité de Fournir: | 500 Piece per Day |
| Payment Type: | L/C, T/T |
| Groupe de produits : | Rogowski Coil |
