Rke Vision Aoi for Rubber Ring Full Automatic CCD Vision Inspection Optical Sorting Machine Device

Prix FOB

Obtenir le dernier prix

1 Minimum Order

Pays:

China

N Â° de modÃ¨le:

Prix FOB:

(Negotiable) Obtenir le dernier prix

LocalitÃ©:

China

Prix de commande minimale:

Commande minimale:

Packaging Detail:

wooden package

Heure de livraison:

40 working days

Capacité de Fournir:

Payment Type:

T/T, Western Union

Groupe de produits :

Contacter maintenant

DONGGUAN RKE INTELLIGENT TECHNOLOGY CO., LTD

China

5000 Points de confiance

1st Année

Personne Ã contacter Ms. Tale

Dongguan, Guangdong

Contacter maintenant

SpÃ©cification du produit

La description

Basic Info.

Model NO.

RK1500

Certification

GS, CE, ISO9001

Condition

New

Application

Electronic Component, Auto Part, Drug, Plastic, Seals, Nail, Bolt, Blind Nut, Nut, Screw

Lens Number

Type

Glass Disc

Transport Package

Wooden Package

Specification

RKE-1900

Trademark

RKE

Origin

China

HS Code

9031499090

Production Capacity

200 Pieces/Month

Product Description

RKE AOI machine , for rubber o -ring products vision inspection , and automatic optical sorting machine, this machine adopts vibration disc feeding, equipped with artificial intelligence visual inspection software, and equipped with 8 CCD industrial cameras. According to customer requirements, it can detect whether the key dimensions of the product, such as inner diameter, outer diameter, height, etc., meet the drawing requirements, as well as whether the surface of the product has appearance defects such as material shortage, pits, white spots, etc. The detection speed is 200pcs/min, and the detection accuracy is ± 0.01mm. According to customer requirements, it is equipped with an automatic packaging machine to complete automatic counting, labeling, packaging and other functions!

Rke Vision Aoi for Rubber Ring Full Automatic CCD Vision Inspection Optical Sorting Machine Device

Thank you for your trust in RKE Intelligent Technology Co., Ltd. We will provide you as following:
Item	Specification
Optical Sorting Machine RK-1900-C8	Inspection Component: size / appearance defective Camera : Hi-Vison Color CCD (200w) *Light Source: RGB cascade multi-angle LED combination lighting, high brightness, 2M pixels tele-centric lens, 5050mm Motor:Japan Panasonic Computer: Dell 2.7G, DDR II 2.0G, 500G , 19" wide screen LCD Software: RKE self-developed(based on labview) Solenoid valve: American Newmandick solenoid valve Power: 220V/50Hz ,1000W Accuracy : ± 0.01mm Detect Speed : 200pcs/min Machine size: 150013001860(2150)mm,Weight: 355KGS Vibrating Device size: 6508001350mm, Weight: 255kgs**

Pays:	China
N Â° de modÃ¨le:	-
Prix FOB:	(Negotiable) Obtenir le dernier prix
LocalitÃ©:	China
Prix de commande minimale:	-
Commande minimale:	1
Packaging Detail:	wooden package
Heure de livraison:	40 working days
Capacité de Fournir:	-
Payment Type:	T/T, Western Union
Groupe de produits :	-
