Rk 1900 Glass Plate Visual Inspection Solution for Connector Optical Sorting Inspection Device

Prix FOB

Obtenir le dernier prix

1 Minimum Order

Pays:

China

N Â° de modÃ¨le:

Prix FOB:

(Negotiable) Obtenir le dernier prix

LocalitÃ©:

China

Prix de commande minimale:

Commande minimale:

Packaging Detail:

wooden package

Heure de livraison:

40 working days

Capacité de Fournir:

Payment Type:

T/T, Western Union

Groupe de produits :

Contacter maintenant

DONGGUAN RKE INTELLIGENT TECHNOLOGY CO., LTD

China

5000 Points de confiance

1st Année

Personne Ã contacter Ms. Tale

Dongguan, Guangdong

Contacter maintenant

SpÃ©cification du produit

La description

Basic Info.

Model NO.

RK1900

Certification

GS, CE, ISO9001

Condition

New

Application

Electronic Component, Auto Part, Drug, Plastic, Seals, Nail, Bolt, Blind Nut, Nut, Screw

Lens Number

Type

Glass Disc

Transport Package

Wooden Package

Specification

RKE-1900

Trademark

RKE

Origin

China

HS Code

9031499090

Production Capacity

200 Pieces/Month

Product Description

RKE 1900 Automatic Vision Inspection Machine for Connector
Optical Sorting Inspection Device

This machine adopts vibration disc feeding, equipped with artificial intelligence visual inspection software, and equipped with 10CCD industrial cameras.

According to customer requirements, it can detect whether the key dimensions of the product, such as inner diameter, outer diameter, height, etc., meet the drawing requirements, as well as whether the surface of the product has appearance defects such as upper and lower surface cracks and burrs.The detection speed is 150pcs/min, and the detection accuracy is ± 0.02mm.

Rk 1900 Glass Plate Visual Inspection Solution for Connector Optical Sorting Inspection Device

Thank you for your trust in RKE Intelligent Technology Co., Ltd. We will provide you as following:
Item	Specification
Optical Sorting Machine RK-1900-C10	Inspection Component: size / appearance defective Camera : Hi-Vison Color CCD (200w) *Light Source: RGB cascade multi-angle LED combination lighting, high brightness, 2M pixels tele-centric lens, 5050mm Motor : Japan Panasonic Computer: Dell 2.7G, DDR II 2.0G, 500G , 19" wide screen LCD Software: RKE self-developed(based on labview) Solenoid valve: American Newmandick solenoid valve Power: 220V/50Hz ,1000W Accuracy : ± 0.02mm Detect Speed : 150pcs/min Machine size: 110010001860(2150)mm,Weight: 355KGS Vibrating Device size: 6508001350mm, Weight: 255kgs**
