| Item | Parameters | |
| Vehicle type | 8 meters electrical bus | |
| Cell | Model | GSF46160M-22 |
| Single Battery Box | Pack Configuration | 8P12S |
| Rated voltage | 38.4V | |
| Rated capacity | 176Ah | |
| Voltage range | 32.4~43.8V | |
| Rated energy | 6.8KWh | |
| Single Box Dimensions (L*W*H) | 662*417*215mm | |
| Battery System | System model | GSBSZH81JAA101.4-576 |
| Pack Configuration | 8P180S (15 boxes) | |
| Rated voltage | 576V | |
| Rated capacity | 176Ah | |
| Voltage range | 486V~657V | |
| Rated energy | 101.4KWh | |
| Rated charge current | 176A | |
| Rated discharge current | 122A | |
| Max. discharge current（30s） | 243A | |
| Communication interface | Vehicle CAN Communication, charger CAN Communication, RS-232 | |
| Power supply | 24V(18~32V) | |
| BMS | Contains BMU, LECU and HMU | |
| Cycle life | ≥2000 | |
| IP degree | IP67 | |
