Prix FOB
Obtenir le dernier prix220 ~ 190 USD / Piece ( Negotiable )
|20 Piece Minimum Order
Pays:
China
N ° de modèle:
NSN-1200/NSN-600/NSN-500/NSN-400/NSN-300
Prix FOB:
220 ~ 190 USD / Piece ( Negotiable ) Obtenir le dernier prix
Localité:
China
Prix de commande minimale:
220 per Piece
Commande minimale:
20 Piece
Packaging Detail:
Standard packing
Heure de livraison:
15-20days
Capacité de Fournir:
1000 Piece per Month
Payment Type:
Other, PayPal, T/T
Groupe de produits :
Personne àcontacter Mr. bill
Changan, Dongguan, Guangdong
NSPV Series Grid-tied Micro
Inverter
The distributed grid-tied micro inverter of The NSPV series from
NEWSUN PV, it
takes the innovative technology . It compared different with
centralized inverter , every
NEWSUN inverter is individual to connect to one solar panel of the
array . There is a
individual MPPT which control every solar panel, and it will get
the maximum power
output from all the other panels even one of them is abnormal.
The NSPV---distributed grid-tied micro inverter have technical
features of high integration
density about electrical design, simple and easy constructed, Easy
Installation. Micro inverter
can be installed with types of photovoltaic module. This is
different with the centralized
inverter and Serial Port Profile inverter which need Consistency
with the modules. Every can
be installed easily under the panel or beside the frame. And the
Micro inverter can connect
with low voltage DC cable directly,
Features of Outdoor grid-tied micro inverter:
1. With imported high-speed main control chip and power device to
improve
system stability.
2. Advanced Maximum Power Point Tracking(MPPT) to ensure the high
efficiency
of system.
3. Efficiency of MPPT >99%.
4. Every Solar panel module connect with a inverter and no Single
Point Of Failure.
5. High-efficiency and frequency transformer, Sufficient
patents.
6. Thorough system protective functions, advanced modular design,
safe and
reliable.
7. Multimode LED status display control function, clear.
8. Frame class :IP67, Compact Construction, easy to install,
operate and
maintain.
| Pays: | China |
| N ° de modèle: | NSN-1200/NSN-600/NSN-500/NSN-400/NSN-300 |
| Prix FOB: | 220 ~ 190 / Piece ( Negotiable ) Obtenir le dernier prix |
| Localité: | China |
| Prix de commande minimale: | 220 per Piece |
| Commande minimale: | 20 Piece |
| Packaging Detail: | Standard packing |
| Heure de livraison: | 15-20days |
| Capacité de Fournir: | 1000 Piece per Month |
| Payment Type: | Other, PayPal, T/T |
| Groupe de produits : | Solar inverter |
