DIESEL GENERATOR SET By Tianjing Yangkang Electrical Co., Ltd,

DIESEL GENERATOR SET

Pays:

China

N Â° de modÃ¨le:

Prix FOB:

(Negotiable) Obtenir le dernier prix

LocalitÃ©:

YANGZHOU

Prix de commande minimale:

Commande minimale:

Packaging Detail:

WOOD CASE/ PLASTIC FILMS

Heure de livraison:

7/10DAYS AFTER RECEIVING THE DEPOSIT

Capacité de Fournir:

Payment Type:

Groupe de produits :

Open Diesel Generator

Output Type: AC Three Phase
Speed: SPEED
Condition: New

La description

DIESEL GENERATOR SET -Engines from Germany

-High pressure common railï¼ŒExcellentï¼ŒEngine managementï¼ŒMap control Systemï¼ŒExcellent Engine Turbocharged and cooling technology, Excellent fuel efficiency and higher emission

-Only MTU engine can operation under an altitude of 3000m without power Derating

-Power range 710-3300KVA

nset Model	GEN-SET SPECIFICATION		Engine Model	Controller	Fuel Consumption (L/H) 100%	Open Genset Dimension ï¼† Weight		Soundproof Genset Dimension ï¼† Weight
nset Model	Standby (kVA) PF:0.8	Prime (kVA) PF:0.8	Engine Model	Controller	Fuel Consumption (L/H) 100%	Dimension (L×W×Hï¼‰mm	Weight (kg)	Dimension (L×W×Hï¼‰mm	Weight (kg)
YK-SL750	750	675	S6R2-PTA	DSE7320	124.0	3560×1420×2050	4885	4800×1800×2500	7000
YK-SL825	825	750	S6R2-PTAA	DSE7320	156.7	3950×1600×2000	5750	6058×2438×2896	10000
YK-SL880	880	800	S612A2-PTA	DSE7320	160.0	3950×1600×1950	6100	6058×2438×2896	13500
YK-SL1168	1168	1062	S12H-PTA	DSE7320	216.1	4600×1750×2500	7800	6058×2438×2896	14000
YK-SL1375	1375	1250	S12R-PTA	DSE7320	260.6	4570×2100×2460	9100	6058×2438×2896	15000
YK-SL1500	1500	1375	S12R-PTA2	DSE7320	272.0	4650×2100×2630	9600	6058×2438×2896	16500
YK-SL1650	1650	1500	S12R-PTAA2	DSE7320	308.0	5000×2200×3000	10000	6058×2438×2896	18000
YK-SL1925	1925	1750	S16R-PTA	DSE7320	347.6	5500×1850×2760	11100	12192×2438×2896	20000
YK-SL2062	2062	1875	S16R-PTA2	DSE7320	398.7	5450×2600×3100	12000	12192×2438×2896	21500
YK-SL2250	2250	2000	S16R-PTAA2	DSE7320	403.8	5850×2450×3430	14400	12192×2438×2896	22000
YK-SL2500	2500	2250	S16R2-PTAW	DSE7320	478.0	6200×2830×3500	15000	12192×2438×2896	24500

â€‹All design for open, Silent, Supper silent, Soundproof, Trailer, container type

1.Alternator - Mingbang/MBKL, Optional Stamford, Leroy Somer, Marathon, JET, Mecc alte.

2.System: control system, ATS system, remote control system, parallel operation system,

3.Control panel: Smartgen , Deepsea,alte
including digital LED genset control model: HGM6120U, DSE7320, DSE6020, AMF20, AMF25

4.Radiator: Equipped with 50°C radiator with fan, enough engine cooling system guarantee long time working

5.Canopy: Generator diesel High-quality steel are thickness canopy -- 2MM to 6MM

6.Material: High density sound-absorbing material -- sound insulation, fireproofing

7.Battery: Generator diesel 12V/ 24V DC battery with charger, battery connects wire

8.Fuel tank: Generator diesel 10-12 hours fuel tank with fuel indicator, long time for working.

9.Protection: Genset High protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker

10.New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.

11.Design: Generator diesel Beautiful & practicably design, Bottom hole for forklift, water outlet & oil outlet for easy maintenance

12.Door: Double open door on both sides of the Gensets.Spacious doors can check for every part of the engine and alternator.
