Prix FOB
Obtenir le dernier prix63 ~ 94 USD / Square Meter ( Negotiable )
|10 Square Meter Minimum Order
Pays:
China
N ° de modèle:
6802999000
Prix FOB:
63 ~ 94 USD / Square Meter ( Negotiable ) Obtenir le dernier prix
Localité:
Tianjin, China
Prix de commande minimale:
63 per Square Meter
Commande minimale:
10 Square Meter
Packaging Detail:
Wooden boxes, pallets
Heure de livraison:
45 days
Capacité de Fournir:
10000 Square Meter per Day
Payment Type:
Other, PayPal, Money Gram, Western Union, D/P, T/T
Groupe de produits :
-
China
Personne àcontacter Mr. lindon
Youyi South Road, Xiqing District, Tianjin, Tianjin
B. Steel skeleton
The columns are made of **0**0*4 hot-dip galvanized square steel
pipes, the beams are made of L*0*4 hot-dip galvanized angle steel,
and M8**0 stainless steel bolts are used. The aluminum alloy
hangers are bolted to the beams. The stone is positioned by
slotting the upper and lower parts, and epoxy resin AB glue is used
for stone installation. The rear buried plate is made of hot-dip
galvanized steel plate.
The beams are arranged throughout the length to improve stability.
The angle steel spans the columns and is welded or connected to the
angle steel by M6 stainless steel bolts to achieve reliable
connection on the columns. The stone slabs and beams are connected
by hangers. The requirements of temperature difference deformation
and building plane deformation are met to the maximum extent.
D. Hanging parts
The styles of hanging parts include T-type, butterfly-shaped, SE
aluminum alloy hanging parts, back bolt type, etc.;
The stainless steel hanging parts are connected to the secondary
keel, and the dry hanging parts have long round holes that can be
adjusted forward and backward, which can effectively ensure the
flatness of the granite curtain wall surface;
The granite and stainless steel hanging parts are reliably bonded
by modified epoxy adhesive, which has a fast curing speed (initial
setting *0min) and has a certain elasticity after curing;
The granite transfers its own weight to the stainless steel hanging
parts through a hard PVC pad with a thickness of not less than 3mm
to avoid rigid contact;
The connection between the beam and the dry hanging parts adopts M8
stainless steel bolts, which can withstand large loads.
F. Fire protection system
The **0mm thick fireproof rock wool and 1.5mm thick galvanized
steel plate are used, with a bulk density of **0Kg/m³, which meet
the fire protection requirements.
| Pays: | China |
| N ° de modèle: | 6802999000 |
| Prix FOB: | 63 ~ 94 / Square Meter ( Negotiable ) Obtenir le dernier prix |
| Localité: | Tianjin, China |
| Prix de commande minimale: | 63 per Square Meter |
| Commande minimale: | 10 Square Meter |
| Packaging Detail: | Wooden boxes, pallets |
| Heure de livraison: | 45 days |
| Capacité de Fournir: | 10000 Square Meter per Day |
| Payment Type: | Other, PayPal, Money Gram, Western Union, D/P, T/T |
| Groupe de produits : | - |
