Portable Tandem Axle Load Scale to measure weight of upto 10000kg.
1.Features：
â‘ Special indicator can be connected to mult-plates for
wheel weight or tandem axle weight testing.
â‘¡ Automatically calculate and print out the data through the
preset overrun axle vehicle models or types.
â‘¢ Built-in high-speed mini printer can print weighing data,
date, time rooms, axle, vehicle weight, limit values.
â‘£ can be the vehicle dynamic and static testing.
2.Technical
Parameter：
①Max Wheel loading：10t,15t,20t,30t,60t
②Plate size：700mmX430mmX27mm(L*H*W)
③Display division：5kg,10kg,20kg
â‘£Accuracy class：Static ±1‰F.S，Dynamic±1%~3%F.S(vehicle
speed < 5Km/h)
Whole accuracy：1% AC/DC Power Supply
Application state-Tandem
Axle Load Scale:
Basic two weighing pads combination,Vehicles weighed at
running.
Single axle passed,The indicator display each axle weight and
whole weight
Single axle max weighing capacity：15TX2 pieces=30T
SCS-XC static and dynamic electronic portable axle
scales,portable axle load meter advantage is that the table is
thin,light weight,
easy to carry.Weighing platform adopt more than sealed tops
sensors embedded into the structure of high-strength
aluminum
weighing station at the bottom, high weighing accuracy,excellent
sealing effect.Widely used inroad transport load control,
highway
law enforcement inspection, automotive safety testing,municipal
waste disposal,etc.,for the development and utilization of axle
load
meter great convenience for Highways, municipal, security and
other sectors.
★ Weighing Range：⑴Wheel load：0~15t （2）axle
load：0~30t （3）whole loading：0~1000t
★ Static accuracy：±1‰ FSï¼›Dynamic：±1.-3% FS
★ Product weight：Weighing pad：28Kg（each） Package
W.t:108kg around.
★ Recommend vehicle speed：3-5 km/h
★ Plate size：700mm×430mm×30mm. Indicator
size：430×335×170mm
★ Built-in high-capacity battery, charging time, can detect
hundreds of times, the available car cigarette lighter power
supply.
